Hobbywing Quickrun 16BL30 G2 ESC & 2435SL 4500KV G3 Motor Combo Losi NASCAR HWI38030002

Hobbywing Quickrun 16BL30 G2 ESC & 2435SL 4500KV G3 Motor Combo Losi NASCAR HWI38030002

SKU HWI38030002
Sold out
$70.00
$70.00 - $70.00
$70.00
$49.99
$49.99 - $49.99
$49.99

  Quickrun 16BL30 G2 ESC & 2435SL 4500KV G3 Motor Combo

  • (1) HOBBYWING QUICRUN 16BL30 G2 ESC package
  • (1) HOBBYWING QUICRUN 2435SL motor package
    ESC Features:
  • Excellent performance, specially designed for 1/16 & 1/18 On-road & Off-Road. Designed to pair with Quicrun 2030/2435 G2 Motor
  • The ESC features intelligent freewheeling technology, delivering higher drive efficiency, lower operating temperatures, improved stability, and greater reliability.
  • Compared to the previous generation 16BL30 ESC, the G2 ESC is significantly smaller: 8.3% shorter in length, 7.1% narrower, and 16.7% lower in height. This design is compact and makes installation easier and allows for cleaner wiring on the chassis.
  • Compared to the G1 ESC, the BEC's continuous current has been upgraded from 1A to 2A, with a peak current of up to 4A. The output voltage can be switched between 6V and 7.4V. Easily powering high-torque and high voltage servos. This provides faster response and more precise control.
  • IP67-rated protection allows it to easily handle harsh environments such as rain, sand, and muddy roads, ensuring reliable performance without environmental limitations.
  • The ESC offers excellent compatibility when paired with QuicRun 2030 G2/2435 G3 motors, delivering smoother control.
  • The power system is suitable for both 1/16th & 1/18th scale hobby vehicles.

 Motor Features:

  • High Efficiency means more POWER while keeping TEMP low!
  • 4 pole rotor design for stronger torque, the motor has strong explosive force.
  • Compared with the previous generation of motors, the output power and efficiency are increased by more than 4%, and the motor temperature is effectively reduced under the same load.
  • 0.2mm thick silicon steel laminations, high strength explosion-proof rotor, high-temperature resistant coil, and imported high-precision and high-quality bearings make the motor super durable.

 Motor Specifications:

  • LiPo Cells: 2S
  • No-load Current (A): 2.1A / 4500kv
  • Dia / Length: D=24mm (0.94") L=36mm (1.42")
  • Shaft Dia / Length: D=2mm (0.08") L=12mm (0.47")
  • Bearing size: D8*D3*T4
  • Pole: 4
  • Weight: 61.2g
  • Applications: 1/16 & 1/18 On-road, Off-road
