Team Exalt Gen-X GOLD Spec 2S Competition 17.5T Brushless Motor Epoxyless Nonepoxy EXAG175GS2
The Team Exalt Gen-X Gold Spec Competition Brushless Motor is engineered for racers who demand precision, consistency, and top-tier performance, delivering a fully integrated system built from the ground up for smooth, efficient power. Every internal component is designed to work cohesively, from the refined stator architecture to the precision-balanced rotor, ensuring predictable output across sanctioned racing classes.
About the Gen-X Gold Spec
Balanced Design & Proven Performance
At the core of the Gold Spec motor is an in-house designed stator optimized to generate strong torque while maintaining stable RPM and legal performance limits. It is paired with a precision-balanced 12.5 millimeter rotor and ceramic bearings to provide fade-resistant power, crisp mid-range punch, and clean throttle response. Advanced cooling channels and a rigid can structure help manage heat during long mains, while the high-accuracy sensor system maintains clear ESC communication from launch to finish. What sets the Gold Spec apart is its specialized, hand-built construction with each motor receiving top-tier stator and rotor selections, less than or equal to 1.0° sensor deviation, and full Motolyser tuning with a performance printout, giving competitive drivers a verified, race-ready advantage.
Features:
Engineered for precision, consistency, and high performance
ROAR approved
Precision-balanced 12.5 millimeter rotor
Ceramic bearings for reduced friction and reliability
Advanced cooling channels with rigid can structure
High-accuracy sensor system for clean ESC communication
Hand-built with top stator and rotor selection
Motolyser-tuned with performance printout
Includes:
(1) Gen-X Gold Spec Competition Brushless Motor (17.5T)
(1) Sensor Cable
Specifications:
TypeBrushless SensoredTurns(17.5T)Input Voltage2SPole/Slot2Max RPM-Motor Length-Motor Diameter-Shaft Diameter1/8in (3.175mm)
Below we have a description of each performance level offered.
Bronze Spec:
This selection is an Unmeasured/ Untouched Spec Motor right out of the box w/ Standard bearings.
Silver Spec:
This selection is a Production built motor that Qualifies as a Top% Stator based on Resistance measured from its batch, including Standard bearings and unmeasured rotor installed sealed from the Team Exalt office with a Silver Spec Seal.
Gold Spec/Specialized:
This selection is a Hand Built Top of the line motor with all the bells and whistles that includes Top % Stator and Rotor of its batch, Sensor Deviation Guaranteed 1.0 Degree or less. Built with precise rotor placement offering maximum performance output, Grade 10 metal shielded Ceramic Bearings installed. Tuned on Motolyser for specific application with Printout and sealed with a Gold Spec Seal of approval!
( Please Note the Specialized motors are tuned on our Motolyser for each application to get you as close as possible when factoring in different Size,Surface, and Climates. Minor adjustments may be required.)
Features:
New 90 Degree Solder tabs
Infinite timing adjustment
Rebuildable design for easy routine maintenance prolonging motor life
High purity copper windings
Ultra-Rare earth magnets for heat resistance and increased longevity
Precision ball bearings
High-Strength and Heat Resistant Magnet Formula
EXAS2305 Rotor Included
High heat resistant pure copper wire
Thermal Epoxy Filled Stator for maximum thermal dissipation.
Replaceable Sensor Board
High RPM Precision Bearings
Roar Approved
